Evo Tactical Handheld Green Laser - Wicked Lasers
Click image for a larger view
Evo

The Evo is an open-source tactical laser that is able to do what you command. Control your Evo wirelessly with your smartphone. Enjoy maximum versatility with fully variable power and 4 operating modes. It's PIC-compatible microcontroller is open source, so you can customize the user interface to fit your needs.

$149.95
75mW+
  • 75mW+
  • 100mW+
Add Smartport
Add Expanded Lens Kit

The world's first open-source handheld laser.

The EVO laser is the most versatile laser we have yet created. SmartPort allows you to control your EVO handheld laser with your smartphone, hack the firmware and more!

Control your Laser with your Phone

It's open-source and smartphone-controllable, so anyone can create apps for it on iOS and Android. The Evo has fully variable power selection and 4 operating modes: momentary, constant, strobe, and bypass. There's even a hidden mode we like to call "Woz mode", requested by the great himself.

Customizable and Upgradeable

The Evo's is crafted from brushed and hard anodized aircraft-grade aluminum. It's easy to add or remove the Smartport from your Evo. Powered by 2xAA batteries, the laser is simple to keep up and running even if you hardly ever put it down - and we've made it more versatile with its rugged tactical lanyard.

Lock and Secure

As the saying goes: "With great power comes great responsibility." These powerful devices are not toys and are for adult use only, so we've built in cipher-locked SmartSwitch technology to give you full control over who can access your laser.

Our Guarantees

We guarantee delivery to every country in the world or your money back. We guarantee your laser will be free from defects for a full year from the date of receipt. We guarantee a 30-day money back return policy. We guarantee that the Evo is 100% legal under U.S. federal law and federal safety requirements.

In order to better serve our customers, we are not accepting preorders at this time. Please sign up below to receive updates on this model's availability.

Accessories
Expanded Lens Kit

The Expanded Lens Kit includes 6 lenses with various effects. Line, Flashlight, Focus, Cross, Floodlight and Galaxy lenses are included.

$29.95
Smartport

Connect your laser to a smartphone using the Smartport. Adding a Bluetooth module will make the connection wireless.

$19.95
Bluetooth Module

Allows your smartport to connect to your smartphone using a bluetooth connection.

$39.95
Firmware Programmer

Use this PIC programmer to customize the user interface of your Evo.

$29.95
Safety Goggles

Crafted out of lightweight polycarbonate, the LaserShades takes into consideration the factors of laser hazards while still providing style and comfort.

$19.95
Technical Specs
Model Name: EVO Series
Laser Product Class: 3B
Wavelength: 532nm
Size: 226.5mm x 25.3mm
Weight: 150g (no battery)
Laser Body: 6061-T6 Aircraft-Grade Aluminum
Laser Finish: Mil-Spec Type III hard anodized in black
Transverse Mode: TEM00
Min Power 75mW, 100mW
Beam Diameter: 2.0mm
Beam Divergence: 1.5mRad
NOHD* 40 meters / 47 meters
Beam distance 0.25 Lux 15012 meters / 17335 meters
Required Eyewear O.D. 2.0+
Voltage: 3V
Power supply: 2x AA 1.5V Alkaline Batteries
Battery Lifetime: 60 - 120 minutes
Switch: Push Button Constant On / Off, Lock-Out Tail Cap, Electronic Mode switch
Modes: Variable Power modes, Momentary, Strobe and Continuous Wave modes, Standby and Secure Lock/Unlock modes
Duty Cycle: Continuous
Expected lifetime: >5,000 hours
Warranty: One Year
FDA Accession No.:

The FDA is the United States Department of Health and Human Services. FDA imports use accession numbers to confirm that a manufacturer has followed the reporting requirements for the product being imported.

Laser Body:

The materials that make up the physical casing of the laser. The outer casing also serves as a heat sink for the laser module inside.

Laser Finish:

The final scratch-resistant finish applied to the laser casing.

Wavelength:

Visible light has a wavelength range of 400-700 nanometers (nm). Between lasers of equal output power (in mW), lasers closest to the peak visibility wavelength of 555nm will have more range and brightness than other wavelengths of laser light. Green lasers (532nm) are closest to the peak visibility wavelength (555nm), and therefore brighter than red, blue, and purple lasers. A laser's wavelength and power are two of the most important factors in choosing a laser. Please click here to learn about how different wavelengths correspond with relative brightness.

Transverse Mode:

In a laser with cylindrical symmetry, the transverse mode patterns are described by a combination of a Gaussian beam profile with a Laguerre polynomial. The modes are denoted TEMpl where p and l are integers labeling the radial and angular mode orders, respectively.

Max Power:

The maximum power level of the laser beam measured in milliwatts (mW). When choosing a laser a higher output power is brighter than a lower output power. For example, a 650nM @ 5mW laser is brighter than a 650nM @ 1mW laser.

Min Power:

The minimum power level of the laser beam measured in milliwatts (mW). When choosing a laser a higher output power is brighter than a lower output power. For example, a 650nM @ 5mW laser is brighter than a 650nM @ 1mW laser.

Beam Divergence:

A measure of how fast the beam expands as the distance from the source increases. The divergence is measured in milliradians (mrad). A low beam divergence is useful for applications like pointing or free-space optical communications.

Beam Shape:

The width of the laser beam @ aperture measured in millimeters.

NOHD

The Nominal Ocular Hazard Distance (NOHD) is the distance that a laser beam does not cause immediate or long term damage to a person. Calculated based on a 0.25 second accidental (unaided eye) exposure.

Beam Distance:

The maximum distance (in meters) at which the laser will produce 0.25 Lux of light. It's the standard that flashlights are measured against.

Required Eyewear O.D.:

Indicates whether or not laser protective eyewear is needed, and the necessary O.D. (optical density) of the eyewear for the laser wavelength being used. The indicated O.D. is the minimum O.D. sufficient to protect the user against a momentary intrabeam or specular reflection exposure.

Power Consumption:

The consumption of energy in the form of electricity. The average power consumption of an incandescent night light is 4W.

Power Supply:

The source by which the laser is powered.

Battery Lifetime:

The average amount of time the battery can last on a single charge.

Switch:

The switches that must be engaged to turn the laser on.

Mode:

The available laser beam modes once the laser is activated.

Duty Cycle:

The time cycle of which the laser can be active without causing damage to the laser module.

Expected Lifetime:

The average expected lifetime that the laser module can be in active use.

Warranty:

The time period for which any damaged or dysfunctional laser resulting from manufacturer's defects or workmanship will be replaced with a new product of the same model. Any attempted disassembly by a user will void the product warranty and may irreparably damage the product. We warrant all laser products sold on www.wickedlasers.com to be free of defects in material and workmanship.

Description

Fully Variable Power Modes

Fully variable power modes including continuous, momentary, strobe and bypass.

Gear Included

Includes pair of LaserShades safety goggles, holster.

Download User Manual

Download the EVO User Manual for detailed laser usage. Quick Start Video.
